소켓(SOCKET)

•

•

  소켓

  Tube size (mm)	L	L1	CODE
  6.35	76.0	36.9	REFPSK0635
  9.52	73.6	36.3	REFPSK0952
  12.70	73.6	36.3	REFPSK1270
  15.88	88.4	41.1	REFPSK1588

엘보 (ELBOW)

•

•

  엘보

  Tube size (mm)	L	L1	CODE
  6.35	47.9	36.9	REFPEL0635
  9.52	47.3	36.3	REFPEL0952
  12.70	50.0	36.3	REFPEL1270
  15.88	57.2	41.1	REFPEL1588

플레어 소켓(FLARE SOCKET)

•

•

  플레어 소켓

  Tube size (mm)	L	L1	CODE
  6.35	53.0	36.9	REFPFS0635
  9.52	54.8	36.3	REFPFS0952
  12.70	58.8	36.3	REFPFS1270
  15.88	68.2	41.1	REFPFS1588

플레어 엘보 (FLARE ELBOW)

•

•

  플레어 엘보

  Tube size (mm)	L	L1	L2	CODE
  6.35	45.6	36.9	30.7	REFPFE0635
  9.52	45.2	36.3	36.5	REFPFE0952
  12.70	50.0	36.3	43.3	REFPFE1270
  15.88	57.2	41.1	48.1	REFPFE1588

유니온 소켓 (UNION SOCKET-FEMALE)

•

•

  유니온 소켓

  Tube size (mm)	L	L1	CODE
  6.35	46.9	36.9	REFPUS0635
  9.52	45.7	36.3	REFPUS0952
  12.70	46.2	36.3	REFPUS1270
  15.88	57.5	41.1	REFPUS1588

유니온 엘보 (UNION ELBOW-MALE)

•

•

  유니온 엘보

  Tube size (mm)	L	L1	L2	CODE
  6.35	48.0	36.9	33.0	REFPUL0635
  9.52	45.2	36.3	41.5	REFPUL0952
  12.70	50.1	36.3	44.3	REFPUL1270
  15.88	57.2	41.1	47.1	REFPUL1588

레듀서 (REDUCER)

•

•

  레듀서

  Tube size (mm)	L	L1	L2	CODE
  6.35 x 9.52	79.8	36.9	35.2	REFPRD0635
  9.52 x 12.70	78.6	36.3	35.3	REFPRD0952
  12.7 x 15.88	86.0	36.3	41.1	REFPRD1270
